ITFF-55
ITFF-55 55" large-area interactive touch foil for digital signage and commercial glass. Professional-grade PCAP, 10-point touch, high durability. From Gerteise.
Reference price: USD 103.00
Downloads
Frequently Asked Questions
Why is 55 inch the default choice for signage?
55" is the highest-volume commercial display size globally — panels, mounts and enclosures are stocked everywhere, and the ITFF-55's 1209.0×680.0mm active area matches standard 55" units exactly.
Can it retrofit a shopping-window glass into a touch display?
Yes. Laminated behind storefront glass with a high-brightness display behind it, the ITFF-55 creates interactive shop windows that work 24/7 — customers browse products on the glass after hours.
Is it durable enough for high-traffic retail environments?
Yes. Professional-grade PCAP with the touch layer sealed behind glass withstands constant public use, and there are no moving parts or surface films to wear out.
Does bright storefront sunlight affect the touch performance?
No. Touch detection is electrical, not optical, so sunlight, spotlights and ambient brightness do not interfere — though the display itself should be high-brightness for daytime visibility.
What does "professional-grade" mean for integrators?
Consistent batch-to-batch quality, stable firmware behavior and full specification documentation — so signage integrators can deploy dozens of units without per-unit debugging.
Can Gerteise supply mixed sizes in one project?
Yes. Multi-size projects (e.g., 55" storefront plus 32" in-store units) can be quoted and shipped together, simplifying procurement for rollouts.
Technical parameters
Technical parameters
| Product structure | G+G . |
|---|---|
| AV dimension description | 55inch . |
| V.A. Size | 1209.0*680.0mm(±0.3mm) . |
| Total Thickness | 4.3mm (±0.3mm) . |
| Outline Dimension | 1282*753mm(-0.3mm) . |
| O.D. Fillet | R10.8mm(±0.3mm)×4 . |
| Coverlens Thickness | 3.0mm(±0.1mm) . |
| ITO Glass Size | 1243.0*711.4mm(±0.3mm) . |
| ITO Glass Thickness | 1.1mm(±0.05mm) . |
| Number of Channels | RX96*TX54 . |
| Touch Technology | PCAP . |
| Support Contact | 10 . |
| Interface form | USB . |
| Work voltage | 5V . |
| Transparency | ≥85% . |
| Haze | ≤3% . |
| Surface hardness | 6H . |
| Operating Humidity | 20%RH-90%RH . |
| Operating Temperature | -20-60℃ . |
